🔌 Anypoint MCP Server

An MCP (Model Context Protocol) server for MuleSoft Anypoint Platform — lets AI assistants like Claude talk directly to your Anypoint APIs.

🎬 Demo

---

✨ Features

Module	Prefix	What it does
🏢 Accounts	accounts_*	Profile, org & environment info
✏️ API Designer	api_designer_*	Browse & manage Design Center projects
📦 Exchange	exchange_*	Search & inspect Exchange assets
🔧 API Manager	api_manager_*	API instances, SLA tiers, contracts
🛡️ API Policies	api_policy_*	Apply & manage API gateway policies
📊 Metrics	metrics_*	Traffic, latency & error rate data
📡 Monitoring	monitoring_*	ARM monitoring queries
🚀 Runtime Manager	runtime_*	CloudHub 2.0 deployments, Start/Stop/Restart
📬 MQ	mq_*	Anypoint MQ queues (sandbox by default)
🔐 Secrets Manager	secrets_*	Secrets Manager vaults & secrets
📋 Reports	reports_*	On-demand aggregated reports

---

🚀 Quick Start

1. Install & build

npm install
npm run build

2. Configure credentials

Create a .env file (a blank template is already included):

ANYPOINT_CLIENT_ID=your-connected-app-client-id
ANYPOINT_CLIENT_SECRET=your-connected-app-client-secret
ANYPOINT_ORG_ID=your-organization-id        # optional if profile has one org
ANYPOINT_ENV_ID=your-environment-id         # default env for API/Runtime Manager tools
ANYPOINT_BASE_URL=https://anypoint.mulesoft.com   # optional, this is the default
MCP_HOST=127.0.0.1
MCP_PORT=3000
MCP_PUBLIC_BASE_URL=https://your-ngrok-host.ngrok-free.dev   # optional, for public UI links

💡 Use a Connected App (Client Credentials grant) from Anypoint Access Management. The server exchanges these for a Bearer token on startup and auto-renews before expiry.

3. Start the server

npm start

The server listens at:

Endpoint	URL
🔌 MCP (Streamable HTTP)	http://127.0.0.1:3000/mcp
❤️ Health check	http://127.0.0.1:3000/health

4. Connect your AI client

Add this to your MCP client config (e.g. Claude Desktop, Agentik):

{
  "mcpServers": {
    "anypoint": {
      "url": "http://127.0.0.1:3000/mcp"
    }
  }
}

---

🐳 Docker

# Build
docker build -t anypoint-mcp-server .

# Run with your .env file
docker run --rm --env-file .env -p 3000:3000 anypoint-mcp-server

---

🛠️ Development

# Build TypeScript
npm run build

# Open MCP Inspector (browser UI to test tools)
npm run inspector

---

🖥️ Interactive UI

Several modules render rich interactive HTML UIs inside MCP-capable clients (like Agentik):

UI	Tool	What you see
🎨 Design Center	api_designer_list_projects	Searchable project carousel
📦 Exchange	exchange_list_assets	Filterable asset table
🔧 API Manager	api_manager_list_apis	API instance table
🚀 Runtime Manager	runtime_list_deployments	Deployment table with Start/Stop buttons
📬 MQ	mq_list_queues	Queue list (defaults to sandbox env)

---

📋 Reports

Generate on-demand aggregated reports with reports_create:

Report type	Description
runtime_flow_count	Flow counts per deployment, grouped by environment
api_manager_insecure_apis	APIs with no policies or missing security policies
metrics_api_health_summary	Traffic, error rates & response times from Metrics API

Reports are cached in memory for the life of the server process.

---

🔒 Auth & Caching

• Token is auto-renewed before expiry — no restarts needed
• Org ID and owner ID are discovered from /accounts/api/profile on startup and cached
• Pass refresh: true to profile/environment tools to force a cache reload
• All API requests include Authorization, x-organization-id, and x-owner-id headers automatically

---

📚 API References

• API Designer Experience API
• Exchange Experience API
• API Manager API
• ARM Monitoring Query API
• AMC Application Manager API
• Anypoint Accounts API
